REED R5044 Non-Contact Phase Rotation Tester

Description REED R5044 Non-Contact Phase Rotation Tester Reed R5044 Datasheet (PDF)   LEDs display motor rotation and phase status. R5044 Offers This motor rotation and 3-phase tester is capable of identifying phase orientation (clockwise or counter-clockwise). The R5044 features non-metal alligator clips that allow for safe non-contact measurements and includes back mounted magnets for easy measurement. Features Non-contact voltage sensing alligator clips promote safety Color-coded leads (red, black, blue) meet IEC 60446 standards LEDs indicate phase orientation (clockwise or counter-clockwise) and whether each phase is live Adjustable LED brightness allows for measurement in sunlight and lowly lit environments Beeper sounds intermittently when detecting correct phase and continuously for a reversed phase Durable housing with magnets frees hands and allows for easy measurement Low battery indicator R5044 Specifications Voltage Detection Method Static Induction Voltage Range 75 to 1000VAC Frequency 45 to 65Hz General Specifications Cable Length 31.5″ (800mm) Cable Color Red (L1)/ Black (L2)/ Blue (L3) Indicators Audible (Buzzer)/ Visual (LED) Adjustable LED Brightness Yes Max. Alligator Clip Jaw Opening 1.18″ (30mm) Magnetic Mounts Yes Auto Shut Off Yes (after 5 minutes without power detection) Power Supply 9V battery Low Battery Indicator Yes Overvoltage Category CAT. III 1000V, CAT. IV 600V Product Certifications CE Operating Temperature 14 to 122°F (-10 to 50°C) Storage Temperature -4 to 140°F (-20 to 60°C) Operating Humidity Range 10 to 80% Dimensions 5 x 2.8 x 1.8″ (128 x 72 x 46 mm) Weight 13.2 oz (375 g) What’s included with the REED R5044 Non-Contact Phase Rotation Tester 3 x Color Coded Cables with Alligator Clips Battery Soft Carrying Case Ideal Applications for the REED R5044 Installing and troubleshooting 3-phase motors, pumps and controls
