Reed R5020-NIST 400A AC Clamp Meter with NCV

Description Reed R5020-NIST 400A AC Clamp Meter with NCV Reed R5020-NIST Datasheet (PDF) Compact AC clamp meter with built-in non-contact voltage (NCV) detector and contact thermometer.   REED R5020-NIST Offers This compact autoranging clamp meter is capable of measuring AC current, AC/DC voltage, resistance, frequency, capacitance, duty cycle and temperature. Featuring double molded plastic housing, the R5020 includes diode check and continuity functions and a non-contact voltage detector built into the clamp tip. Features Measures AC current, AC/ DC voltage, resistance, capacitance, frequency, duty cycle and temperature 4000-count LCD display with low battery and overrange indicators Built-in non-contact voltage detector with LED indicator Display hold and relative mode Diode test and continuity check functions Durable double molded plastic housing Cat. III 600V safety rating REED R5020 Specifications AC Current Range 40, 400A Accuracy AC: ±(2.5% rdg. 8 dgt.) Resolution 0.01, 0.1A AC/DC Voltage Range AC: 4, 40, 400, 600V DC: 400mV, 4, 40, 400, 600V Accuracy AC: ±(1.8% rdg. 8 dgt.) DC: ±(1.5% rdg. 2 dgt.) Resolution AC: 0.001, 0.01, 0.1, 1V DC: 0.1mV, 0.001, 0.01, 0.1, 1V Resistance Range 400Ω, 4, 40, 400kΩ, 4, 40MΩ Accuracy ±(1.5% rdg. 2 dgt.) 0.1Ω, 0.001, 0.01, 0.1kΩ, 0.001, 0.01MΩ Capacitance Range 40, 400nF, 4, 40, 100µF Accuracy ±(3% rdg. 5 dgt.) Resolution 0.01, 0.1nF, 0.01, 0.1μF Frequency Range 10MHz Accuracy ±(1.2% rdg. 2 dgt.) Resolution 0.01Hz Temperature Range -4 to 1400°F (-20 to 760°C) Accuracy ±(3.0% rdg. 9°F) ±(3.0% rdg. 5°C) Resolution 1°F, 1°C General Specifications Range Selection Autoranging / Manual Display 4,000 count LCD display Display Hold Yes Relative Mode Yes Diode Test Yes Continuity Check Audible signal if resistance <150Ω Duty Cycle Yes Non-Contact Voltage Detector Yes Autoshut off Yes (after 15 mins) Power Supply 2 x AAA Low Battery Indicator Yes Jaw Opening 1.2″ (30mm), up to 350 MCM Overvoltage Category CAT. III 600V Product Certifications CE Operating Temperature 32 to 122°F (0 to 50°C) Storage Temperature -4 to 140°F (-20 to 60°C) Dimensions 7.9 x 2.6 x 1.5″ (200 x 66 x 37 mm) Weight 7.2oz (205g) What’s included with the REED R5020 AC Clamp Meter Test Leads Thermocouple Wire Probe Thermocouple Adapter Batteries Soft Carrying Case Calibration Certificate Ideal Applications for the REED R5020 Industrial maintenance teams performing scheduled and preventative maintenance on electro-mechanical equipment and systems. Facilities, building maintenance and electricians looking to troubleshoot electrical equipment installation problems.
